Solar Panel Direction and Tilt Angles for the Best Harvest

Comprehensive guide to optimising your solar energy production in the UK. Discover optimal tilt angles and seasonal adjustments for maximum energy efficiency.

Solar panel on adjustable stand with protractor indicating tilt angles, illuminated by sunbeams showcasing energy absorption efficiency.

The Earth’s axis is tilted, causing variations in the sun’s path across the sky throughout the year. Therefore, a solar panel’s tilt angle governs how much solar energy it captures throughout the year.

In This Article:

    Solar Angle And Generation Calculator

    This calculator will give you an average yearly yield estimation using the optimal angle for the approximate latitude of your selected location (city, country, state, etc.).

    Simple Solar Energy Generation Calculator

    *Using approximate latitude

    What is the Best Position for Solar Panels in the UK?

    For optimal energy production in the UK panels need to point South. The next best directions are East and West, with insignificant differences.

    In the following table, we see a comparison of how tilt angle and panel orientation affect yearly production. The annual PV production is measured in kWh.

    Estimated yearly generation for a single 430W panel
    Direction40° (optimal angle)0° flat52.537.5°67.5°
    South440.8 kWh336 kWh427 kWh434 kWh398 kWh
    East343 kWh336 kWh322 kWh343 kWh289 kWh
    West336 kWh336 kWh313 kWh336 kWh281 kWh
    North215 kWh336 kWh173 kWh223 kWh133 kWh

    According to this calculation, the best position is south-facing at ~40°.

    I calculated the optimal angle value using this calculator.

    Using the calculator mentioned above, you can calculate your system’s estimated annual PV energy production, too. The field for tilt angle is named Slope, and the field for direction is named Azimuth.

    Why Flat Solar Panels Mounting is Suboptimal?

    The table above indicates that flat panels perform better than some at steeper angles. However, depending on how best to use the produced energy, we may want to optimise for other factors.

    When using solar energy to power our homes, we should prefer more consistent output compared to huge production in summer and minimal to no output in winter. Let’s see how the generated energy spreads over the year.

    To emphasise the point, let’s look at two sub-optimal positions. We’re comparing a flat panel against a 90° wall-mounted south-facing panel.

    Diagram showing the output of a flat solar panel. Barchart.
    Flat panels produce well in the summer and struggle in the winter. Yearly production 336kWh.
    Diagram showing the output of a flat solar panel. Barchart.
    A wall-mounted panel gives much better consistency and peaks in spring and autumn than in summer. Yearly production 295kWh.

    From this analysis, we can conclude that if you are installing panels for the purpose of selling electricity at a flat rate, then you are better off going with a flat tilt angle. However, if you are optimising for year-round home consumption, and your choice is between a flat or wall-mounted one, go for the wall-mounted one.

    This advice is nuanced. The further from the equator you are, the stronger the advice applies to you. Inversely, the closer you are to the equator, the worse you are for following this advice Theoretically, the best position at the equator is a flat mount.

    Solar Panel Tilt Angles for UK Cities

    CitySummer TiltWinter TiltOptimal Calculated (Year-Round)
    Southampton35.9°65.9°40°
    London36.5°66.5°40°
    Birmingham37.5°67.5°40°
    Newcastle39.9°69.9°43°
    Edinburgh40.9°70.9°42°
    Aberdeen42.1°72.1°43°

    For the optimal value calculation I used the calculator by the European Commission’s Photovoltaic Geographical Information System.

    For more details, see Source World estimates of PV optimal tilt angles and ratios of sunlight incident upon tilted and tracked PV panels relative to horizontal panels, Department of Civil and Environmental Engineering, Stanford University, Stanford, CA 94305-4020, USA. The paper offers a comprehensive table of recommended tilt angles for all countries.

    What are some Solar Panels Angles for Optimal Performance Worldwide

    From our analysis of three comprehensive studies, the following recommendations emerge:

    1. Latitude-Based Tilt: A general rule of thumb suggests setting the tilt angle approximately equal to the geographical latitude of the location. For example, with a latitude of 51.5°N, London would have an optimal tilt angle of roughly 51.5°.
    2. Adjustments for Seasons: Some experts recommend adjusting the tilt angle seasonally. In summer, a tilt angle of 15° less than the latitude might be more effective when the sun is higher. In contrast, an angle of 15° more than the latitude in winter can capture more sunlight.

    Note: The exact optimal tilt can vary based on local conditions, such as obstructions or specific weather patterns.

    Optimal Tilt Angles Based on Latitude with City Examples

    Latitude RangeMajor CitiesOptimal Tilt (Year-Round)Summer TiltWinter Tilt
    0° – 10°Bogota, JakartaLatitudeLatitude – 15°Latitude + 15°
    10° – 20°Mumbai, Mexico CityLatitudeLatitude – 15°Latitude + 15°
    20° – 30°Cairo, New DelhiLatitudeLatitude – 15°Latitude + 15°
    30° – 40°Athens, Los AngelesLatitudeLatitude – 15°Latitude + 15°
    40° – 50°London, TokyoLatitudeLatitude – 15°Latitude + 15°
    50° – 60°Glasgow, OsloLatitudeLatitude – 10°Latitude + 20°
    60° – 70°Reykjavik, TromsøLatitude + 5°LatitudeLatitude + 25°
    70° – 80°Longyearbyen, NuukLatitude + 10°Latitude + 5°Latitude + 30°

    Can You Have Solar Panels at Different (Mixed) Angles?

    Yes, you can have solar panels installed at different angles. There are a few strategies to achieve this. Microinverters or solar optimisers are the most effective way to approach this problem.

    Garage with solar panels facing in different direction. Four panels on the roof and one panel on a wall which is perpendicular to the roof.
    There wasn’t enough space on the roof, so I installed one panel on the wall. It helps in winter. I am using Tigo optimisers, but the plan is to replace them with a microinverter.

    These high-level components allow each solar panel to operate independently, maximising the energy production of each panel regardless of the angle or orientation.

    Another way to solve this problem is to explore different connections. You can choose to wire in parallel or series to counteract the adverse effects of difference in performance due to the sub-optimal angles in part of your string.

    It’s important to note that having solar panels at different angles can make your solar energy system more complex to design, install, and maintain. If in doubt, seek advice from a professional solar installer to help with optimising your system for maximum energy production.

    Can I install horizontal solar panels?

    Horizontal installation of solar panels has its advantages and disadvantages.

    Advantages:

    1. Ease of Installation: Horizontal panels require no special mounts or tilting mechanisms.
    2. Work Well In Cloudy Weather: In overcast conditions flat panels can produce better results than panels at larger tilt angles.
    3. Aesthetics: For homeowners concerned about the visual impact, flat panels might blend more seamlessly with the roof.

    Disadvantages:

    1. Reduced Efficiency: Solar panels tilted at 0° might not capture sunlight as effectively as those tilted optimally, especially in higher latitudes.
    2. Snow Accumulation: Flat panels can accumulate snow in snowy regions, blocking sunlight and reducing energy production.
    3. No Self-Cleaning: The minimum angle for self-cleaning is 10°.

    My Experience With Nearly Flat Panels

    In May 2024 I built a solar gazebo to expand my PV capacity. The location where I built the gazebo falls under height regulation from the local Building Regulations authority. Hence, I had little room to work with on the roof angle. My initial plan was to maximise the tilt, however after some aesthetic optimisation I ended up with a 6° agnle.

    Image of nearly flat solar panels where rain water has collected at the bottom of the panel. Nex to it is the same image from later on, when the water has dired and the residues remained on the solar panels.
    At 6° tilt angle, the panels on my solar gazebo will require regular cleaning to remove the dust that the rain couldn’t wash away.

    In the images above, you can see how rainwater cannot fully drain from the panels. This means that part of the dust the rain washed down from the panel remains as residue and builds up under those puddles.

    What is the Minimum Angle for Solar Panels?

    There is no minimum angle as an absolute value. However, it is recommended that solar panels be installed at a tilt angle of at least 10°. This angle allows rainwater to wash away dust and debris, and it is also referred to as the minimum angle for self-cleaning. As stated in the paper by Stanford University quoted above, even at the equator, where the optimal angle theoretically is 0°, installers tilt panels at 10° to allow rainwater to wash away efficiently.

    At What Angle Do Solar Panels Stop Working?

    Solar panels don’t exactly “stop working” at any specific angle, but their efficiency can significantly decrease if the angle isn’t optimal. Solar panels work by absorbing sunlight and converting it into electricity.

    The more direct sunlight the solar panels receive, the more electricity they can generate.

    If the angle is too steep or flat relative to the sun’s position, the sunlight will hit the panels at an oblique angle, reducing the energy they can produce. For instance, a solar panel that’s lying flat (0-degree tilt) will produce less electricity in the winter months when the sun is low in the sky. Conversely, a solar panel standing upright (90-degree tilt) will produce less electricity in the summer when the sun is high in the sky.

    However, the angle can’t be so steep or flat that the solar panels stop working. Even at less-than-optimal angles, solar panels will still produce electricity as long as they receive sunlight.

    In conclusion, while the angle can significantly impact the efficiency of solar panels, it won’t cause them to stop working. With the right planning and design, you can optimise your solar energy system to produce a significant amount of electricity throughout the year, regardless of the angle of your solar panels.

    Installing Solar Panels On A Flat Roof

    The straightforward approach is to install your panels flat along the roof. However, as discussed above, flat mounts have disadvantages.

    Solar panels on flat roofs or the ground are installed at an angle to mitigate the adverse effects of horizontal mounting. Angling is achieved using frames holding the panels at the desired tilt. These frames are typically held down by ballast weight from concrete blocks and some mounting equipment vendors offer flat roof mounting trays that can be filled with sand for ballast.

    Illustrative Ballasting Requirements for Flat Roof Solar Panels in England

    RegionAverage Annual Wind Speed (m/s)Recommended Ballast Weight (kg)Note
    Southeast (e.g., London)4 – 640 – 50Urban areas require less ballast due to windbreaks.
    Southwest (e.g., Bristol)5 – 750 – 60Coastal areas require more ballast due to higher wind speeds.
    Midlands (e.g., Birmingham)4 – 640 – 50Urban areas require less ballast.
    Northwest (e.g., Manchester)5 – 850 – 65Coastal and hilly regions need more ballast.
    Northeast (e.g., Newcastle)5 – 850 – 65Coastal and hilly regions need more ballast.
    Yorkshire (e.g., Leeds)4 – 745 – 60Varied requirements based on local geography.

    Please note the above values are illustrative. The weight requirements depend on how high the roof is and what conditions are expected in your environment. For example, areas with typical strong winds, like coastal areas, will require extra weight to be added.

    It’s important to understand that while calculations can provide a baseline or starting point, actual recommendations often come from a combination of calculations, real-world testing, industry standards, and practical experience. Ballast weights also need to counteract maximum wind speed. The maximum wind speed in London is around 30 m/s.

    1. Safety Margins: It’s common practice to apply a safety margin when determining ballast requirements. For instance, if calculations suggest a weight of 5 kg is required, a safety factor of 3 might be applied, leading to a recommendation of 15 kg.
    2. Wind Gusts & Turbulence: Average wind speeds don’t account for gusts, which can exert significantly higher forces. Turbulence, especially in urban areas, can also increase the effective wind speed at the panel’s location.
    3. Other Forces: The potential for wind to get underneath a panel and lift it can significantly increase the required ballast weight. This is especially true if the panel is not entirely flush with its mounting surface.
    4. Conservatism: In engineering, especially where safety and property damage are concerns, it’s common to err on caution.

    Consider the height of the roof where panels are installed too. Wind speed increases with the increase in height. This is due to the frictional effects of the ground or obstacles on the wind, which slow it down at lower levels. Here is an illustrative increase of wind speed at typical residential floor heights.

    • Ground 0m: 0m/s (This is the base value; in practice, there will be a non-zero wind speed at ground level, but for our calculations, we used this as the reference point)
    • First Floor 3m: 6.95m/s
    • Second Floor 6m: 8.56m/s
    • Third Floor 9m: 9.67m/s

    Conclusion

    The tilt angle of the solar panels plays a significant role in your system’s optimal energy production. Solar panel installation in the UK will benefit from angles tilted at 40° more than it would from flat panels. The optimal angle depends on the latitude, and additional seasonal adjustments can be beneficial.
